Creality CV-01 Laser Engraver
Compact diode engraver with an all-in-one stand, simple assembly, and offline TF-card workflow. The SD card here bundles manuals, ready-to-run G-code, and training videos so you can carve your first design in minutes. If you are searching for the official Creality CV-01 software download, the link below is the current CrealityLaser V1.0.1 package.
Creality CV-01 Software Download & Guide
The official Creality CV-01 software (CrealityLaser V1.0.1) is provided here as a direct download for Windows, alongside the full user manual, quick-start instructions, and operation videos. This section highlights the engraver’s 1.6W blue diode, 170x200 mm work area, and the offline TF-card workflow so you can engrave without a tethered PC.
Use the “Download CrealityLaser V1.0.1” button above for the latest Creality CV-01 software package, and explore the ready-to-run G-code library below for plywood, card, kraft paper, and felt. Each G-code links back to the matching preview image so you know exactly what you are running.
Highlights
- Four knurled nuts snap the X-axis onto the base; plug the motor and limit-switch leads and you are mechanically ready.
- Three engraving modes in CrealityLaser: Outline, Grayscale, and Black-white with live threshold preview.
- Material presets with adjustable power and speed; width and height auto-lock to preserve aspect ratio.
- Offline-first: export G-code, drop it on the TF card, and the machine will run the first file it finds after reset.
- Sample projects included for linden plywood, card stock, kraft paper, and felt so you can test without hunting art.
- Hardware specs: 1.6W blue diode (450nm), 170×200 mm work area, 416×360×137 mm footprint, 1.8 kg net weight.
Quick Start
- Assemble: place the X-axis over the Y frame, align the posts, tighten four knurled nuts, and connect the stepper and limit switch plugs.
- Install software: run the bundled CrealityLaser installer (`2.Software/CrealityLaser V1.0.1 en.exe`).
- Prep artwork: open an image, choose Outline/Grayscale/Black-white, adjust threshold if needed, and position it in the preview area.
- Set parameters: pick a material preset or dial power/velocity, confirm size and placement stay inside the green frame, then export G-code.
- Run offline: copy only the target `.gcode` to the TF card (delete any old BIN or prior G-code), power on, focus with the lens knob until the spot is smallest, frame the job with the panel buttons, and start.
Included Assets
- User manual V1.1 (PDF): full guide
- Quick operation instruction V1.1 (PDF): assembly + workflow
- CrealityLaser V1.0.1 (Windows): installer (zip bundle)
- How-to videos: operation overview (download), Y-belt tension (download)
- Starter G-code packs sorted by material: linden plywood, color card paper, kraft paper, and color asphalt felt.
Sample art
TF card ready
Offline friendly
Material Tips
- Good fits: copy paper, corrugated paper, plywood/plank, acrylic, fabric, leather.
- Avoid: PVC/vinyl or anything chlorine-bearing; they release corrosive fumes that harm users and optics.
- Keep stock flat, clean, and dry; place a metal spoil board under thin sheets to prevent burn marks through-cutting.
- Use Grayscale for detailed photos, Black-white for high contrast art, and Outline for vector-like cuts.
Key Specs
Safety & Workflow Reminders
- Always wear the supplied goggles and keep good ventilation; never leave a burnable job unattended.
- Use a metal backer under thin stock to prevent marking the bed if the beam cuts through.
- The machine runs only the first G-code on the TF card; delete old BIN/G-code files before each job.
- Focus by turning the lens knob until the spot is smallest; recheck focus after changing material thickness.
- Watch the belt tension video if the Y-axis skips (belt setup).
Samples & Ready-to-Run G-code
Browse the visuals, then grab the matching G-code for your material. Copy only the chosen file to the TF card (remove old BIN/G-code), focus the lens, frame, and start.
Downloadable G-code
